Description
|
Model No |
MW-DW60 |
|
Laser type |
Nd:YAG |
|
Laser wavelength |
1064nm |
|
Average power |
60W |
|
Maximum power |
100W |
|
Single pulse energy |
40J-60J |
|
Pulse width |
0.1-10ms |
|
Frequency |
1-10Hz |
|
Laser adjusting scope |
±3mm |
|
Beam diameter size |
0.1-2.0mm |
|
Observation |
CCD+Microscope (combined) |
|
Electricity |
220V/50Hz |
|
Dimension |
510*295*395mm |
|
Machine weight |
28kg |
1.CCD screen+ mircro combined observation ,can watch the whole welding process;
2.Adjustable parameters (such as energy, pulse width, frequency, spot diameter), can achieve different requirements of welding;
3. Continuous working for 24 hours, the performance of the whole machine is stable;
4. The laser beam can realize the splitting of time and energy, and can process multiple beams at the same time. The welding speed is obviously improved, so that users can complete processing orders with high efficiency and high quality in a short time;
5.laser working hours can reach 10 0000 hours;
6. size is very small and portable .only 28kgs ,can save your space.
