Description
|
SPECIFICATIONS FOR LASER MOULD WELDING MACHINE |
|||
|
Type |
MW-200M |
MW-300M |
MW-500M |
|
Three Axis Table |
X=250mm,Y=180mm |
||
|
Table Capacity |
≤200KG |
||
|
Machine Battery |
220V±10%/50/60z |
380V±10%/50/60Hz |
|
|
Laser Type |
Nd:YAG Pulse Xenon Lamp |
||
|
Spot Adjusting Range |
0.1~3mm |
||
|
Peak Wavelength |
1064nm |
||
|
Pulse Width |
≤20ms |
||
|
Rated Output Power |
180W |
270W |
460W |
|
Maximum Laser Power |
200W |
300W |
500W |
|
Pulse Frequency |
≤50Hz |
||
|
Laser Output Focal Length |
100mm |
||
|
Laser Cooling |
Water Cooling |
||
|
Monitor |
Microscope( Rotate 360º) |
||
|
Protective Gas |
1(argon) |
||
|
Cold Water Capacity |
2700W |
3500W |
6500W |
|
Wire Diamter |
0.1mm~0.6mm |
0.1mm~0.8mm |
0.1mm~1.0mm |
|
Dimension |
Main Machine : 1250*580*1200mm |
||
1.Antomatic table with rotary: machine can weld various shapes of mold and have good performance in flat and cylinder soldering.
2.Wide range of application: all kinds of metal like gold,sillver,bronze,aluminum.steel and titanium
3.High power with high speed, the energy power of laser can reach 100J,and freqency of laser can be increased.
4.Easy operation,the laser control system is very simple,user can learn it after only 20 minutes training.
1. UK ceramic light-gathering cavity, anti-corrosion, heat-resistance, chamber(8-10 years of life), more than 8 million times life of Xenon lamp;
2. Using the World's most advanced automatic shading system, It eliminates the stimulation to the eyes in work;
3.Laser head can rotate 360 degrees, overall light path can rotate 360 degrees, electric lift up and down, driving front and back, especially suitable for all kinds of large, medium and small mould repair;
4.Parameter adjustment adopts intelligent remote control, simple and quick operation;
5.Three-dimensional moving workbench can be electric hoist;
6.Light spot size electric regulation;
1. Core technology. When we were a small factory, we have focused on the development of core components such as laser power supplies and optical path. Unlike other suppliers, they only sell through assembly equipment.
2. Independent research and development department. This means we can offer our customers customized machines and improve the equipment according to market changes
3. Dealer support plan. In the early stage of customers' market development, we provide technical parameters for the installation and use of equipment free of charge, share good marketing methods, help customers win the market and achieve success.
4. Strict testing. All of the suppliers we work with come from world-class manufacturers. Before the delivery, each machine needs to be tested and inspected for 48 hours (marking machine, welding machine) and 4-7 days (cutting machine) to ensure quality and safety.
5. Timely delivery. Each machine has an accurate assembly process and strict time control to ensure that customers receive goods in a timely manner.
6. After-sales service and guarantee. We offer a 2-year warranty and any problems occur during the period and we have a responsibility to resolve them. If any part of the machine is broken, we will repair it for free and send free accessories.
